JOBSITE PRODUCTS ASPHALT PAVERS
Sponsored By
R&D Hydraulics Trench Paver The R&D asphalt trench paver attaches to your equipment to provide faster production with less labor. • Lays over 1,800 tons a day • Fully adjustable for mat depth and trench widths between 16 and 60 in. • Mounts easily to front-end loaders ForConstructionPros.com/10086399
Caterpillar AP500F/ AP555F Asphalt Pavers
Roadtec RP-195e Asphalt Paver Roadtec's powerful, rubber-track highway class RP-195e paver is powered by 230-hp Cummins QSB 6.7 Tier 4 Final-compliant diesel engine. • Anti-segregation design encompasses the feed tunnel, feed tunnel discharge and rear augers • Fully oscillating bogies and smooth tread aide in laying a smoother mat • Operator stations hydraulically swing out, allowing the operator to see down the side of the machine • Consoles - one of which contains the single joystick control - are located at the operator’s fingertips and the operator’s seat is adjustable for optimal comfort • Clearview FXS fume extraction system pushes fumes away from operator and keeps line of sight clear ForConstructionPros. com/12055680
The wheeled AP500F and AP555F with Mobil-Trac undercarriage feature advanced, easy-to-use control technology and quick-heating electric screeds. • 144-metric-hp C4.4 ACERT Tier 4 Final engine with Eco-Mode setting and automatic engine-speed control • AP500F available with six-wheel drive, as well as a front-wheel assist or four-wheel-drive option
• SE50 V (vibratory-only) screed offers a 21.3-ft. maximum paving range and the SE50 VT (vibration and tamperbar) screed provides 26.3-ft. widths • Integrated generator brings the screed to proper temperature in about 15 minutes • Touchscreen, high-visibility color displays with user-friendly options for accessing available control system technology ForConstructionPros. com/12185721
Volvo P7110B and P7170B Tier 4 Final Pavers The P7110B tracked and P7170B wheeled pavers offer 360° visibility, improved fuel efficiency with 12+ hours of continuous runtime without refueling and options to enhance productivity and mat quality. • Volvo D8J, 8-liter, Tier 4 Final engine uses continuous passive regeneration and boasts a more than 5% improvement in fuel efficiency • Press of a button extends the twostage, 42-in. hydraulic tunnels, allowing head of material control without bolt-on extensions • Include a range of screed options and a four-sensor material flow • Choice of two control consoles for operation from the left or right sides • Side air vents and a slightly higher seat improve operator comfort ForConstructionPros. com/12185798
Clarence Richard EZ-Temp Indicator Sensor The EZ-Temp Indicator Sensor from Clarence Richard uses a continuous readout that monitors temperature variance of the paving mat.
Vögele Super 1700-3i and Super 1703-3i Pavers The Super 1700-3i tracked and Super 1703-3i wheeled 8-ft. pavers effectively counteract thermal and mechanical segregation via an optimally designed receiving hopper, ascending conveyors and hydraulic augers that allow height to be adjusted by 6 in. • With the ErgoPlus 3 screed console, the front-mounted extending screed can be adjusted infinitely variably and rapidly from 8 ft. to 15 ft. 6 in., or up to 19 ft. 6 in. with hydraulic bolt-on extensions • The extra-large receiving hopper has a capacity of 14.3 tons ForConstructionPros.com/12306990
www.ForConstructionPros.com/Asphalt
ACON0821_44-51_Pavers_JD.indd 45
• Designed to improve rolling performance and job quality using the latest infrared technology • EZ Calibration Control features one-time adjustment for accurate temperature reading • Durable all-weather design ForConstructionPros. com/12229698
AUGUST 2021 ASPHALT CONTRACTOR
45 7/20/21 3:32 PM
